Current Projects

Exo Marine DH550 - Kit Build in Germany.

Placeholder Picture

The turn continued without problem. Due to the early onset of the secondary task of beer drinking, I failed to get a final photo of the hull upright.

Placeholder Picture

Pascal demonstrating the ancient art of hull surfing.

Placeholder Picture

The dagger slides and dagger board were supplied by Exocetus as part of the kit. At this point we commenced the secondary task of emptying Peters fridge of beer.

Placeholder Picture

At the half way point the dagger board was inserted and checked for fit.

Placeholder Picture

The port hull had already been turned a few days before. The operation was stress free and the epoxy finish on the hull skin is excellent.

Placeholder Picture

In October we went to Peters place to help turn his second Hull
Here the hull is hanging on several winches waiting for the turn to begin

Placeholder Picture

First step installation

Placeholder Picture

The preformed radius profiles supplied with the Exocetus kit allow for easy installation and minimal fairing.

Placeholder Picture

Both hulls are being built at the same time

Placeholder Picture

Peter is making good progress with side and bottom skins installed and radius skin 80% completed. Build was started mid November 2015 with two men working 2 or 3 days a week progress is very good taking into consideration this is an amateur build by guys who have not built a boat before.

Placeholder Picture

The skin section is bonded in position in a single operation.

Placeholder Picture

The skin section is 'dry fitted' to check alignment and mark bonding areas for the application of epoxy.

Placeholder Picture

The hull skins can be installed individually but the best results are achieved by bonding as many skin sections as possible into a large section on a flat surface before bonding to the hull frame.

Even larger skin sections can be handled with a single chain block..

Placeholder Picture

In August last year we supplied a DH550 kit to a customer in Germany. Progress has been very good with the Hull skin installation due to start imminently.

Placeholder Picture

This customer is a home builder and is fortunate to have enough space to build both hulls at the same time.
